PLC Control 10 Heads Gravity Bottle Filling Machine For 1 - 5L Bleach Cleaner

Brand Name : STRPACK

Model Number : STR

Certification : ISO,CE

Place of Origin : CHINA

MOQ : 1

Price : Price Negotiable

Payment Terms : TT/LC

Supply Ability : 1000 SET

Delivery Time : 3-50 Working Days

Packaging Details : Wooden Case Packaging

Filling accuracy : ≤±1.5%

Filling quantity : 500~5000ml

Filling heads : 8, 12, 16, 18, 20

Filling range : Can be customized according to customer's request

Production capacity : 1200~4000bottle/hours

Working gas source : 0.6~0.8MPa

Contact Now

10 Heads Automatic Gravity Bleach Liquid Bottle Filling Machine For 1-5L Bleach Cleaner Corrosive Liquid Cleaner

Our SFL series anti corrosive filling machine are widely used in corrosive liquid filling. We choose the filling heads according to production capacity buyers want per hour. we are the first compamy in china who make the machines in anti-corrosive standard and can offer best solution with a lot of experience.
Major characteristics on strong liquid filling machine
This non-metal filling machine specially designed for strong acid and alkali product, such as: hydrochloric acid products bleach.


Introduction:


Anti corrosive liquid filling machine is mainly aimed at 84 disinfectant, household detergent, bleach water, net liquid stains, clean the toilet, cleaning the toilet, diluent, bleach, disinfectant, thinners and other water-based materials and design of the machine. This machine integrates light, machine, electricity, gas integration, PLC control, touch screen operation. Design simple, easy to use, stable and reliable. The machine use PVC anti-corrosion materials, it is especially suitable for super corrosion, filling, can satisfy the requirement of all kinds of shape of the container filling.


Major characteristics:


Anti Corrosive Strong 84 Disinfectant Liquid Cleaner Bleach Filling Machine with 12 Filling Nozzles for Corrosive Liquid

(1)PLC controlled ,friendly touch screen control.

(2) Famous brand electrical and pneumatic components used to guarantee machines quality and long lfie service time.

(3) Bottom up filling nozzle.

(4) Vacuum suck back for dripping can be special designed for foamy product.

(5) All wetted parts are made of non-metal materials,which anti-foamy.

(6)Not only whole filling heads can be adjusted,but each filling head can be fine-adjusted respectively.

(7)Bottle inlet counting,quantative filling,bottle outlet counting ,and serious motions can be done automatically.

(8)Simple structure,easy operation, Low noise ,reliable running, accurate filling.


Parameter:


ItemSFL-4SFL-8SFL-12SFL-16SFL-20
Filling nozzle48121620
Filling scope20-5000ml20-500ml
Idea filing range20-100ml 50-250ml100-500ml200ml-1000ml500-2500ml1000-5000ml
Capacity(BPM)40-6060-8070-9080-10090-120(1 line)
130-160(2 line)
Filling precision20-1000ml: ≤±1% 1000-5000ml: ≤±0.5%
Air pressure0.4~0.6MPa
Voltage220V 50/60Hz
Power0.75kw0.75kw1.2kw2.2kw2.2kw
Noise≤50dB
N.W.500kg800 kg1000 kg1300kg1500kg
Dimension(mm)1300×1000×18001600×1000×18001900×1000×18002300×1000×18002600×1000×1800



After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD60.00/day/person.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
